Solid Bowl

Perforate

NEW: MRU 100 Magnesol Removal solid basket centrifuge.

Max bowl speed 4000 RPM, 2000 G's, rated @ 5 GPM. 1.375 gal sludge cap, 9 x 9" bowl, quick-release bowl top, 1 HP motor 230/460/3/60/1775 RPM, mounted on stand Bowl is nickel-plated carbon steel, covers & frame are coated with epoxy paint to resist corrosion. Filters solid part


Barrett Centech 1000 system with 125 Clarifuge, SS.

For contaminated cutting oil or coolant with little or no tramp oil. Sludge-bearing liquid is pumped to the 2 HP Clarifuge where sludge is removed @2100 Gs, liquid flows back to the 170 gal clarifier tank & is recircu- lated through the Clarifuge for the time required to obtain the


Barrett 612-L Liquifuge liquid-liquid separator, 316SS.

Max bowl speed 3450 RPM, 1000 G's, rated @ 2 GPM (7.5L) 12"x 6" bowl, .75 gallon solids capacity. 3 HP motor w/ flexible hoses & control panel, mounted on 40" x 48" tank w/manual. 1987 vintage. Excellent condition.


De Laval 12 x 5.5 solid basket centrifuge, SS.

Max bowl speed 3300 RPM, 1855 G's, capacity .2 cu ft. max load 50 lbs, 1 HP XP motor 115/1/60 with XP on/off switch and cord. Unitized on skid. Very good condition. Missing top cover.


Barrett Centech 2500 system with 236 Clarifuge, SS.

For contaminated cutting oil or coolant with little or no tramp oil. Sludge-bearing liquid is pumped to the 3 HP Clarifuge where sludge is removed @2100 Gs, liquid flows back to the 255 gal clarifier tank & is recircu- lated through the Clarifuge for the time required to obtain the


Barrett 236 Clarifuge centrifuge, SS.

Max bowl speed 3450 RPM, 2200 G's, rated @ 5-8 GPM, 2 gal sludge cap, 13 x 6" bowl, 3 HP motor 230/460/3/60 mounted on sub-base. 2002 vintage. Excellent condition. Bowl lip cut back a bit for heavy carbide particles. Fiberglass casing. Spare NEW bowl included.


Sharples Mark III solid bowl basket centrifuge, 316SS.

Max bowl speed 3250, 2100 G's, model 3PP-350H, 14" x 6" solid bowl with 4 vertical baffles. 2 HP motor 208/230/ 3/60 variable speed hydraulic drive & braking system, fumetite/sterile design, wash pipes, feed pipes, vents, skimming nozzles, belt guard & control panel. Unitized on a porta


Rousselet DRC 50 VxAV1S conical solid bowl centrifuge, 316L

Max bowl speed 2250 RPM, 1410 x G, 20" x 12.6" bowl ID, max load 37 kgs, bowl volume 30 L, sanitary design, 7.5 HP XP motor 460/3/60, sight glass, lamp port, feed pipe, pneumatically actuated cover w/lock, speed sensor AC variable frequency drive, automatic liquid skimmer, motorized


(2) ATM DeLaval 20 x 14 solid bowl basket centrifuges, SS.

Max bowl speed 1800 RPM, 900 G's, 7.5 HP motor 230/460/ 3/60/1775 RPM, skimmer assembly, brake, sight glass and NEMA 4 control panel. Reconditioned & unused since.


ATM/De Laval 20 x 14 solid basket centrifuge, 316SS.

Max bowl speed 1775 RPM, 900 G's, top unload, 5 HP motor 230/460/3/60/1735 RPM, feed tube, sight glass & control panel. Rebuilt 1998 & unused since.


Rousselet DSC 85-K solid basket centrifuge, SS.

Max bowl speed 1450 RPM, max load 160 kg, 850 x 470mm. 11 KW motor 380/3/50/1450 RPM, adjustable skimmer tube, removable basket. Very good condition. FCA Europe.


Rousselet DSC 85 AV 1S solid basket centrifuge, 316SS.

Max bowl speed 1450 RPM, max load 160 kg, 850 x 470mm. 11 KW motor 380/3/50/1450 RPM, adjustable skimmer tube, removable basket. Very good condition. FCA Europe.


Rousselet DSC 120 HX DEC 1S solid basket centrifuge, 316SS.

Max bowl speed 1150 RPM, max load 390 kg, 1200 x 600mm. 22 KW motor 380/3/50/1450 RPM, adjustable skimmer tube, removable basket. Very good condition. FCA Europe.


(2) Microseparator CF-55M coolant clarifiers, 304SS.

Max bowl speed 2400 RPM, rated @ 12 GPM, manual clean, 1.75 gal rotor volume, 2 HP motor 230/460/3/60/1725 RPM 304SS rotor, rubber liner, aluminum cover & casing, cover limit switch, 1 HP feed pump & control panel. Very good condition.


Microseparator TSK-50M coolant clarifier, 304SS.

Max bowl speed 2400 RPM, rated @ 12 GPM, manual clean, 1.75 gal rotor volume, 2 HP motor 230/460/3/60/1725 RPM 304SS rotor, rubber liner, aluminum cover & casing. Good condition. Sludge cap 430 cuin or .25 cuft.


NEW: US Centrifuge M212 solid basket centrifuge.

Aluminum bowl and cover, rated @ 10 GPM, manual clean, 1500 x G, 1 gallon solids capacity, 2.5 gal bowl volume 2 HP motor 220/440/3/60, feed cone, PVC bowl liner and manual. Full OEM warranty. Many options available.


US Centrifuge M512 solid basket centrifuge.

Aluminum bowl and cover, rated @ 10 GPM, manual clean, 1500 x G, 1 gallon solids capacity, 2.5 gal bowl volume 2 HP motor 220/440/3/60, SS feed cone & impeller assbly PVC bowl liner, control panel & feed pump, unitized on portable cart. Excellent condition.


Hoffman Filter CCF-21 coolant clarifier, rubber bowl.

Max bowl speed 2400 RPM, rated @ 12 GPM, manual clean, 1.75 gal rotor volume, 2 HP motor 230/460/3/50/60/1450/ 1730 RPM. Unitized on a skid with control panel. Equivalent to: Microseparator TSK-50M. 2004 vintage. Excellent condition.


Sanborn T5B-03 Turbo Separator.

Aluminum bowl and cover, 1600 x G, rated @ 8 GPM on oil 13 GPM on coolant, 0.8 G sludge capacity to 2-5 microns 1 HP motor 220/440/3/60, feed cone, 2 sludge baskets, cover lock, controls and manual. 2002 vintage. Prior use: Glass dust from water. Very good condition.


UNUSED: Sanborn LiquaPac HS TMC coolant clarifier.

Max bowl speed 2400 RPM, 1000 x G, rated @ 30 GPM max. 1.4 gal sludge cap, feed accelerator, aluminum bowl, 3 HP motor 230/460/3/60/1725 RPM, feed pump, controls. 1995 vintage. Never used. Spare rubber liner.


NEW: Western States 6 x 3.6 lab perforate basket centrifuge

Max bowl speed 5000 RPM, 2130 x G, cGMP sanitary design 56.5 cuin solids capacity, 68 sqin filtration area, basket lifts off spindle w/o need for tools, disposable paper or cloth filter media. Slurry feed with .5" ball valve & wash/spray line with tri-clamp fittings, 3" sight glas


Kokusan 10 x 6 lab perforate basket centrifuge, 316SS.

Max bowl speed 3000 RPM, 1500 x G, 3-4.5L capacity. 1 KVA variable speed drive 115/1/50/60/3000 RPM. 1997 vintage. Excellent condition.


Western States 12 x 6 perforate basket centrifuge, 316SS.

Max bowl speed 3600 RPM, 2500 G's, capacity .36 cu ft. Top cover, sight glass, feed tube, skimmer tube, 3 HP XP hydraulic motor 230/460/3/60/1800 RPM, unitized on portable cart with XP control panel. Excellent cond. Includes several poly filter bags.


Tolhurst 12 x 6 perforate basket centrifuge, SS.

Max bowl speed 2900 RPM, 1400 G's, capacity .168 cu ft. Top cover, sight glass, 1/2 HP XP motor 115/230/1/60 and start/stop control panel. Very good condition.


Ametek 12 x 5 perforate basket centrifuge, Kynar-lined.

Max bowl speed 2900 RPM, 1400 G's, capacity .168 cu ft. Top cover, sight glass, 1 HP XP motor 230/460/3/60/3450 and start/stop control panel mounted on portable skid. Excellent condition.


Bird 12 x 8 perforate basket centrifuge, SS.

Max bowl speed 3400 RPM, top-mounted 1 HP XP motor. Very good condition.


NEW: ACME 12" x 8" perforate basket centrifuge, Hastelloy.

Max bowl speed 3000 RPM, 1500 x G, 10 L cake volume. Top unload, full body opening (flip top), sanitary de- sign, explosion-proof motor with VFD, feed & rinse pipe and XP control panel, unitized on a portable skid. All wetted parts are Hastelloy C22. One year warranty. Voltage wi


NEW: ACME 12" x 8" perforate basket centrifuge, Hastelloy.

Max bowl speed 3000 RPM, 1500 x G, 10 L cake volume. Top unload, full body opening (flip top), sanitary de- sign, 2 HP motor with VFD, feed & rinse pipes, safety interlock, sight glass, unitized on a portable cabinet. All wetted parts are Hastelloy C22. One year warranty. Voltage wi


NEW: ACME 12" x 8" perforate basket centrifuge, 316SS.

Max bowl speed 3000 RPM, 1500 x G, 10 L cake volume. Top unload, full body opening (flip top), sanitary de- sign, explosion-proof motor with VFD, feed & rinse pipe unitized on a portable skid. Allow 8 weeks for delivery One year warranty. HMI XP controls available: add $5K.


Sharples Mark III perforate basket centrifuge, 316SS.

Max bowl speed 3250, 2100 G's, model 3PP-350H, 14" x 6" 2 HP variable speed hydraulic drive 208/230/3/60/3450, fumetite design, braking system, feed & wash pipes, vents, belt guard & controls. Unitized on a skid. Reconditioned with full mechanical warranty.


Sharples Mark III perforate basket centrifuge, 316SS.

Max bowl speed 3250, 2100 G's, model 3PP-350H, 14" x 6" 2 HP variable speed hydraulic drive 208/230/3/60/3450, fumetite design, braking system, feed & wash pipes, vents, belt guard & controls. Unitized on a skid. Very good condition.


Sharples Mark III perforate & solid basket centrifuge, 316S

Max bowl speed 3250, 2100 G's, model 3PP-350H, 14" x 6" 2 HP variable speed hydraulic drive 208/230/3/60/3450, fumetite design, braking system, feed & wash pipes, vents, belt guard & controls. Unitized on a skid. 1984 vintage. Very good condition. Two separate bowls, perforate


Western States 14 x 6 perforate basket centrifuge, 316SS.

Max bowl speed 3600 RPM, 2500 G's, capacity .36 cu ft. Flip top cover, sight glass, feed tube, hydraulic drive XP control panel, unitized on portable skid. Excellent condition.


Western States 14 x 6 perforate basket centrifuge, 316SS.

Max bowl speed 3500 RPM, 2500 G's, capacity .36 cu ft. Flip top cover, sight glass, feed tube, hydraulic drive 3 HP XP motor 220/440/3/60/1800 RPM, XP control panel, unitized on portable skid. Very good condition. 1980 vintage.


Western States 14 x 6 perforate basket centrifuge, 316SS.

Max bowl speed 3500 RPM, 2500 G's, capacity .36 cu ft. Flip top cover, sight glass, feed tube, hydraulic drive 3 HP XP motor 220/440/3/60/1800 RPM, XP control panel, unitized on portable skid. Excellent condition.


Heinzen SD-50 14 x 20" lettuce spin dryer, SS.

Max bowl speed 1800 RPM, 650 G's, 32 G basket, 50 lb. capacity, 20 cycles/hr, 1.5 HP motor 230/460/3/60/1750, soft start VFD controller, airbrake system, vibration sensor, adjustable timer and safety interlocks. Excellent condition.


Western States 14 x 6 perforate basket centrifuge, 316SS.

Max bowl speed 3500 RPM, 2500 G's, capacity .36 cu ft. Flip top cover, sight glass, feed tube, hydraulic drive 3 HP XP motor 220/440/3/60/1800 RPM, XP control panel, unitized on portable skid. Excellent condition. 1986 vintage.


Western States 14 x 6 perforate basket centrifuge, 316SS.

Max bowl speed 3500 RPM, 2500 G's, capacity .36 cu ft. Flip top cover, sight glass, feed tube, hydraulic drive 3 HP XP motor 220/440/3/60/1800 RPM, XP control panel, unitized on portable skid with digital tachometer. High pressure design STM-1000-146 with mechanical seal, air purge


Ketema 16 x 6 perforate basket centrifuge, 316SS.

Max bowl speed 1875 RPM, 800 G's, capacity .45 cu ft. Top cover, sight glass, feed tube, 1.5 HP XP motor with VFD control, mounted on portable cart w/cooling jacket for continual batches. All sanitary grade use; acid passivation. Includes poly bags: 25 and 5 micron mesh. 1987 vinta


NEW: ACME 18" x 8" perforate basket centrifuge, SS.

Top unload, full body opening (flip top), sanitary, all flame proof, skid-mounted, portable, has a VFD and a hydraulic power pack to open the monitor casing. The electricals will be as specified. Delivery: 8 weeks.


NEW: ACME 18" x 10" perforate basket centrifuge, Hastelloy.

Max bowl speed 1800 RPM, 825 x G or 2450 RPM, 1500 x G. 28 L cake volume, top unload, full body opening (flip top), sanitary design, explosion-proof motor with VFD, hydraulic powerpack to open the cover, feed & rinse pipes, XP control panel, unitized on a portable skid. Voltage wi


Tolhurst 20" X 12" perforate basket centrifuge, 316SS.

Max bowl speed 1600 RPM, 5 HP hydraulic motor, feed tube & sight glass.


Rousselet RC50VxR perforate basket centrifuge, Hastelloy.

Max bowl speed 2250 RPM, 1410 x G, 20 x 12.6" basket ID max load 37 kgs, sanitary design, automatic filter bag removal & lifting assembly, top unload w/hinged cover, feed & rinse pipes, 10 HP motor 230/460/3/60/1755 RPM, skid-mounted with control panel. Prior use: Pharmaceuti 2000 vinta


Ellerwerk 931 L perforate basket centrifuge, 316SS.

Max bowl spd 3000 RPM, 2250 G's, max load 36 KG. 5.5 KW XP motor 380/660/3/50/1450 RPM, jacketed 6 bar, Mounted on skid. 1989 vintage. Very good condition. FCA Europe.


Fletcher 20 x 12 perforate basket centrifuge, 316SS.

Max bowl speed 1400 RPM, 2 HP motor 220/440/3/60/3500 and foot brake. Excellent condition.


Tolhurst 20" X 12" perforate basket centrifuge, 316SS.

Max bowl speed 1600RPM, top unload, 2 HP motor 440/3/60 feed tube & sight glass. Very good condition.


Bock 10-XC 15 x 12 perforate basket centrifuge, 304SS.

Max bowl speed 1725 RPM, 633 G's, rated @ 10 lbs/batch, removable basket, vaportite cover & timer control. .25 HP motor 230/3/60. Very good condition.


Bock 205 20 x 12 perforate basket centrifuge, 304SS.

Max bowl speed 1700 RPM, 800 G's, rated @ 35 lbs/batch, removable basket, vaportite cover & timer control. 2 HP motor 230/3/60. Very good condition. 1990 vintage.


24" X 12" perforate basket centrifuge, Teflon coated SS.

Max bowl speed 1200 RPM, top unload, 5 HP XP hydraulic drive 220/440/3/60/1740 RPM with XP controls on stand. Good condition. No nameplate.


ALA CPT-630, 25" X 16" perforate basket centrifuge, 316SS.

Max bowl speed 1900 RPM, 1280 G's, max load 80 kg. 4 KW motor 220/380/3/50 & control panel unitized on portable skid. 1984 vintage. Excellent condition. FCA Europe.
