FKC HX-600 screw press for fish dewatering, 304 SS.

Rated @ 1000-3000 KPH, dehydrated moisture 81.5%, screens 1.5 x 2.8p x 1.0t / 1.2 x 2.3 x 1.0 / 1.0 x 2 x 0.8 with hopper. Excellent condition. Sumitomo gearbox available - NEW or rebuilt.


Alfa-Laval ALDEC 10 decanter centrifuge, 316SS.

Max bowl speed 5300 RPM, 3140 G's, 7.9 x 27.9" bowl ID. 4" single lead hardsurfaced conveyor, 11 KW motor 460/3 /60/3550 RPM, 45.6:1 gearbox, 3.3 KW backdrive, guards, feed tube, vibration isolators/switch, mounted on stand with chutes. New bearings; good running condition. 2010 vinta


Alfa-Laval ALDEC 10 decanter centrifuge, 316SS.

Max bowl speed 5300 RPM, 3140 G's, 7.9 x 27.9" bowl ID. 4" single lead hardsurfaced conveyor, 11 KW motor 460/3 /60/3550 RPM, 45.6:1 gearbox, 3.3 KW backdrive, guards, feed tube, vibration isolators/switch, mounted on stand with chutes. Very good condition. 2011 vintage.


Alfa-Laval SG2-100 decanter centrifuge, 316SS.

Max bowl speed 5300 RPM, 3140 G's, 7.9 x 27.9" bowl ID. 4" single lead hardsurfaced conveyor, 11 KW motor 460/3 /60/3550 w/VFD, 45.6:1 gearbox, 3.3 KW backdrive w/VFD, guards, feed tube, vibration isolators/switch, mounted on stand with chutes and control panel. 2009 vintage. Very good


Alfa-Laval NX 309 decanter centrifuge, 316SS.

Max bowl speed 5600 RPM, 4000 G's, eccentric plate dams 2" single lead hardsurfaced conveyor, 20 HP motor 230/ 460/3/60/3560 RPM, cyclo gearbox w/hydraulic backdrive, feed tube, guards, vibration isolators/switch, mounted on platform w/starter & push button control. Very good


Alfa-Laval VNNX 409S-31G sanitary decanter, 316SS.

Max bowl speed 6200 RPM, 5205 x G, 9.2 x 27.6", pump on liquid discharge, 3.5" double lead hardsurface conveyor 15 KW motor 220/380/3/50/2910 RPM, cake vibrator, 1:25 cyclo gearbox, feed tube, guards, vibration isolators and control panel mounted on a stand. 1995 vintage. Reconditio


Alfa-Laval NX 309S-31G decanter centrifuge, 316SS.

Max bowl speed 5600 RPM, 4000 x G, 9.2 x 27.6", pump on liquid discharge, 3.5" double lead hardsurface conveyor 15 KW motor 220/380/3/50/2910 RPM, cake vibrator, 25:1 cyclo gearbox, feed tube, guards & vibration isolators. 1983 vintage. Excellent condition. FCA India.


Alfa-Laval NX 309S-31G decanter centrifuge, 316SS.

Max bowl speed 5600 RPM, 4000 x G, 9.2 x 27.6", pump on liquid discharge, 3.5" double lead hardsurface conveyor 20 HP motor 575/3/60/3550 RPM, cake vibrator, 25:1 cyclo gearbox, feed tube, guards & vibration isolators. Mounted on a stand. 1978 vintage. Good condition.


De Laval NX 210B-31E decanter centrifuge, 316SS/Sanitary.

Max bowl speed 3250 RPM, conical bowl, hardsurfaced conveyor, 15 HP motor 220/440/3/60/1800 RPM and 159:1 gearbox unitized on base. Prior use: Food.


De Laval AFNX 210-31B decanter centrifuge, 316SS.

Max bowl speed 3250 RPM, conical bowl, 5" double lead hardsurfaced conveyor, 15 HP motor 220/440/3/60/1800RPM 159:1 gearbox w/TA assembly, guards & feed tube, unitiz on a stand with feed pump. Excellent condition.


Alfa-Laval NX 210 decanter centrifuge, 316SS.

Max bowl speed 3250 RPM, conical bowl, 5" double lead hardsurfaced conveyor. No motor, no gearbox. Very good condition.


Alfa-Laval NX 912 decanter centrifuge, 316SS.

Max bowl speed 4400 RPM, 3030 G's, 11 x 49.6" bowl ID. 5" single lead STC-tiled conveyor, 15 KW motor 380/3/50 1.5 knm 97:1 gearbox w/backdrive, CIP spray header, feed tube, guard, vibration isolators/switch, mounted on a stand with chutes and control panel. FCA Africa. Very good


Alfa-Laval NX 214-31BE decanter centrifuge, 316SS.

Max bowl speed 3250 RPM, 110mm single lead hardsurfaced conveyor, hi-temp bearings, 30 HP motor 460/3/60/1800, 159:1 gearbox w/TA assembly & limit switch, feed tube, guards, vibration isolators and control panel. Unitized on 56" high stand. Includes 100 gallon SS liquid tank, chutes, ma


Alfa-Laval CFNX 414B-31G decanter centrifuge, 316SS.

Max bowl speed 4000 RPM, 110mm single lead hardsurfaced conveyor, 18 KW motor 380/3/50/1500 RPM, 159:1 gearbox w/TA assembly & limit switch, feed tube, guards, vibra- tion isolators and control panel. Unitized on a stand. Reconditioned with full mechanical warranty. FCA Europe


Alfa-Laval NX 314B-31G decanter centrifuge, 316SS.

Max bowl speed 4000 RPM, 110mm single lead hardsurfaced conveyor, 15 KW motor 380/3/50/1500 RPM, 159:1 gearbox w/TA assembly & limit switch, feed tube, guards and vibration isolators. Unitized on a stand. FCA Europe. Prior use: Fishmeal. Excellent condition. Spare rota


Alfa-Laval CFNX 414B-31G decanter centrifuge, 316SS.

Max bowl speed 4000 RPM, 110mm single lead hardsurfaced conveyor, 18 KW motor 380/3/50/1500 RPM, 159:1 gearbox feed tube & belt guard. Very good condition. FCA Europe 1980 vintage.


Alfa-Laval NX 314B-31G decanter centrifuge, 316SS.

Max bowl speed 4000 RPM, 110mm single lead hardsurfaced conveyor, 15 KW motor 380/3/50/1500 RPM, 159:1 gearbox w/TA assembly & limit switch, feed tube, guards and vibration isolators. Unitized on a stand. FCA Europe. 2008 vintage. Excellent condition.


Alfa-Laval PONX 414 decanter centrifuge, 316SS.

Max bowl speed 4000 RPM, 30 HP motor 230/460/3/60/1800 159:1 2.5 Knm gearbox, guards, feed tube, on stand. 2004 vintage. Prior use: Fishmeal. Very good condition.


Alfa-Laval MRNX 414S-31G decanter centrifuge, 316SS.

Max bowl speed 4000 RPM, effluent discharged under pressure, 110mm single lead sanitary conveyor, 22 KW motor 380/3/50, 159:1 gearbox, feed tube, guard and vibration isolators, mounted on 3' stand. 1986 vintage. Reconditioned w/12 mo. mechanical warranty. FCA Europe.


Alfa-Laval NX 414S-11G tricanter centrifuge, 316SS.

Max bowl speed 4000 RPM, 3158 x G, 110mm single lead sanitary conveyor, 22 KW 415/3/50/1470, 159:1 gearbox, feed tube, guard, vibration switch/isolators on stand. Prior use: Edible fats. Reconditioned. FCA NZ.


Alfa-Laval NX 414S-31G decanter centrifuge, 316SS.

Max bowl speed 4000 RPM, effluent discharged under pressure, 110mm single lead sanitary conveyor, 30 KW motor 380/660/3/50, 159:1 gearbox, feed tube, guards, vibration isolators, mounted on 1' stand with chutes & control panel. 1981 vintage. Excellent condition. FCA UK.


Alfa-Laval NX 314B-31G decanter centrifuge, 316SS.

Max bowl speed 4000 RPM, 3157 x G, epicentric liquid dams, 110mm single lead hardsurfaced conveyor, wear pro tected discharge ports, 20 HP motor 230/460/3/60/3450, 159:1 gearbox, torque arm assembly, feed tube, guards & vibration switch. Excellent condition.


Alfa-Laval ALDEC 402 (NX 414B-31G) decanter, 316SS.

Max bowl speed 4000 RPM, 3157 x G, epicentric liquid dams, 110mm single lead hardsurfaced conveyor, wear pro tected discharge ports, 15 KW motor 400/3/50/3000 RPM, 159:1 gearbox, torque arm assembly, feed tube, guards & vibration switch on stand. Excellent condition. 2002 vinta


(4) Alfa-Laval CFNX 414B-31G decanter centrifuges, 316SS.

Max bowl speed 4000 RPM, 110mm single lead hardsurfaced conveyor, 18 KW motor 380/3/50/1500 RPM, 159:1 gearbox feed tube & belt guard. Very good condition. FCA Europe


Alfa-Laval NX 314B-11G tricanter centrifuge, 316SS.

Max bowl speed 4000 RPM, 110mm single lead hardsurfaced conveyor, 30 HP motor 460/3/60/1800 RPM, 159:1 gearbox w/TA assembly & limit switch, feed tube, guards and vibration isolators. Unitized on a stand with chutes. Very good condition.


Alfa-Laval UVNX 714B-11G tricanter centrifuge, 316SS.

Max bowl speed 4000 RPM, 110mm single lead hardsurfaced conveyor, 15 KW motor 460/3/60/1800 RPM, 159:1 gearbox w/TA assembly & limit switch, feed tube, guards and vibration isolators. Unitized on a stand with chutes. Reconditioned.


Alfa-Laval NX 314B-31G decanter centrifuge, 316SS.

Max bowl speed 3250 RPM, epicentric liquid dams, sheave feed tube, rotating assembly, base & casings. No motor, no gearbox. Very good condition.


(2) Alfa-Laval NX 314B-31G decanter centrifuges, 316SS.

Max bowl speed 4000 RPM, 3157 x G, epicentric liquid dams, 110mm single lead hardsurfaced conveyor, wear pro tected discharge ports, NEW 20 HP motor 230/460/3/60, 159:1 gearbox, torque arm assembly, feed tube, guards, vibration switch/isolators and control panel. Unitized on a commo


Alfa-Laval AVNX 719B-31G decanter centrifuge, 316SS.

Max bowl speed 4000 RPM, 3100 x G, 20 deg beach angle, 70mm single lead STC-tiled conveyor, 159:1 gearbox, 30 KW motor 380/3/50, 4 KW backdrive, guards, feed tube Containerized with pumps, chutes and control panels. Very good condition. Bowl ID 14 x 46" (353 x 1160mm). Rated @ 37


Alfa-Laval AVNX 419B-31G decanter centrifuge, 316SS.

Max bowl speed 4000 RPM, 3100 x G, 20 deg beach angle, 70mm single lead STC-tiled conveyor, 159:1 gearbox, 30 KW motor 380/3/50, 4 KW backdrive, guards, feed tube vibration switch/isolators. Very good condition. FCA Europe. Bowl ID 14 x 46" (353 x 1160mm).


Alfa-Laval NX 716B-31G decanter centrifuge, 316SS.

Max bowl speed 4000 RPM, 3100 x G, adjustable liquid ports, lined cake ports, 110mm single lead hardsurfaced conveyor, 15 KW motor 380/3/50/1450, 159:1 2.5 gearbox, feed tube & guards, unitized on 4' high stand. Rated @ 80 GPM on light visc. oils, 14 x 46" bowl ID. 1998 vinta


Alfa-Laval ALDEC 404 decanter centrifuge, 316SS.

Max bowl speed 4000 RPM, 3100 x G, adjustable liquid ports, lined cake ports, 110mm single lead hardsurfaced conveyor, 15 KW motor 415/3/60/1750, 159:1 2.5 gearbox, feed tube, guards, chutes & control panel on 4' stand. Rated @ 80 GPM on light visc. oils, 14 x 46" bowl ID. 2003 vinta


Alfa-Laval AVNX 919/4045B-31G decanter centrifuge, 316SS.

Max bowl speed 4000 RPM, 3100 x G, 20 deg beach angle, 70mm single lead STC-tiled conveyor, 159:1 gearbox, 30 KW motor 380/3/50, 4 KW backdrive, guards, feed tube Trailer-mounted with chutes, pumps and control panels. Very good condition. Bowl ID 14 x 46" (353 x 1160mm). Rated @ 37


Alfa-Laval AVNX 4045 AT decanter centrifuge, 316SS.

Max bowl speed 4000 RPM, 3100 x G, 20 deg beach angle, 110mm single lead STC-tiled conveyor w/baffle disc, 30 KW motor 380/3/50/1450, 159:1 2.5 gearbox, backdrive feed tube, guards, vibration detection system & chutes. Unitized on a stand with control panel & spare conveyor 14 x 46" b


Alfa-Laval AVNX 419B-31G decanter centrifuge, 316SS.

Max bowl speed 4000 RPM, 3100 x G, 20 deg beach angle, 70mm single lead STC-tiled conveyor, 159:1 gearbox, 30 KW motor 380/3/50, 4 KW backdrive, guards, feed tube Containerized with pumps, chutes and control panels. Very good condition. Bowl ID 14 x 46" (353 x 1160mm). Rated @ 37


NEW: Alfa-Laval NX 418B-11G three-phase decanters, 316SS.

Max bowl speed 4000 RPM, 70mm single lead hardsurfaced conveyor, double row of lined cake ports, 160:1 gearbox 37 KW variable speed motor 415/3/50/1450 RPM, 22 KW flux vector backdrive, vibration switch/isolators, feed tube, guards and regenerative drive/control system. FCA Austra


NEW: Alfa-Laval NX 3650 decanter centrifuge, 316SS.

Max bowl speed 4200 RPM, 3550 x G, liquid discharged by gravity, 110mm single lead TC hardsurfaced conveyor, 40 HP direct drive 460/3/60/1800 RPM with VFD, guards, 159:1 2.5 knm gearbox, vibration switch/isolators and NEMA 4 control panel. Mounted on 4' stand with chutes. Delivery:


NEW: Alfa-Laval NX 3650 tricanter centrifuge, 316SS.

Max bowl speed 4200 RPM, 3550 x G, liquid discharged by gravity, 110mm single lead TC hardsurfaced conveyor, 40 HP direct drive 460/3/60/1800 RPM with VFD, guards, 159:1 2.5 knm gearbox, vibration switch/isolators and NEMA 4 control panel. Mounted on 4' stand with chutes. Full OEM w


Alfa-Laval NX 418 decanter centrifuge, 316SS.

Max bowl speed 4000 RPM, 3180 x G, adjustable liquid dams, wear liners on feed zone and cake ports, 110mm single lead STC tiled conveyor, 40 HP motor 460/ 3/60/1750 RPM, gearbox, backdrive (failed), feed tube, guards, vibration switch/isolators, grease lubricated bearings,


Alfa-Laval FPNX 418B-31G decanter centrifuge, 316SS.

Max bowl speed 4000 RPM, 3158 G's, liquid discharged by gravity, 110mm hardsurfaced Esbjerg conveyor, 30 KW ABB motor 380/3/50/1450 RPM, Viscotherm hydraulic back- drive system, guards, feed tube, chutes, piping, valves mounted on SS stand, sanitary feed pump, solids take- away conve


NEW: Alfa-Laval FOODEC 300 decanter centrifuge, 316SS.

Max bowl speed 4200 RPM, 3550 x G, liquid discharged by gravity, 125mm single lead Esbjerg polished conveyor 30 HP direct drive 460/3/60/1800 RPM with VFD, guards, 52:1 3.5 knm gearbox, 15 HP backdrive with VFD, NEMA 4X control panel, NEMA 12 VFD controls. Mounted on 4'stand w/chutes.


Alfa-Laval NX 418B-31G decanter centrifuge, 316SS.

Max bowl speed 4000 RPM, 3158 G's, liquid discharged by gravity, 110mm hardsurfaced Esbjerg conveyor, 40 HP motor 230/460/3/60/1750 RPM, 15 HP backdrive, guards, 159:1 gearbox, feed tube, chutes and control panel. 1997 vintage. Excellent condition. FCA India.


Alfa-Laval AVNX 4040 decanter centrifuge, 316SS.

Max bowl speed 4000 RPM, 3158 x G, liquid discharged by gravity, single row of cake discharge ports, adjustable effluent dams, 110mm single lead hardsurfaced conveyor, 22 KW motor 400/3/50, 15 KW backdrive, gearbox, guards, feed tube, vibration isolators/switch & chutes unitized on a stand


Alfa-Laval MRNX 418S-31G sanitary decanter, 316SS.

Max bowl speed 4000 PRM, 3158 G's, liquid discharged under pressure, 70mm polished Esberg conveyor, 30 HP motor 480/3/60/1800 RPM, 7.5 HP vari-speed backdrive, 159:1 gearbox, guards, vibration switch/isolators and NEMA 4 control/starter panel. Mounted on 4' SS frame. Includes c


Alfa-Laval NX 418S-31G decanter centrifuge, 316SS.

Max bowl speed 4000 RPM, 3158 G's, liquid discharged by pump, 110mm hardsurfaced Esbjerg conveyor, 30 KW motor 400/3/50/1495 RPM, 2.5 kNm 159:1 gearbox, guards 4 KW backdrive, feed tube, vibration switch/isolators and control panel. Very good condition. FCA Europe.


Alfa-Laval NX 4050B-31G decanter centrifuge, 316SS.

Max bowl speed 4000 RPM, 3158 x G, liquid discharged by gravity, 110mm single lead hardsurfaced conveyor, 40 HP motor 440/3/60, 159:1 gearbox, feed tube, guards, vibration switch/isolators & chutes, mounted on stand. 2003 vintage. Very good condition. FCA India.


Alfa-Laval NX 418B-31G decanter centrifuge, 316SS.

Max bowl speed 4000 RPM, 3158 G's, liquid discharged by gravity, 110mm hardsurfaced Esbjerg conveyor, 30 HP motor 380/3/50/1495 RPM, 5.5 KW backdrive, guards, 159:1 gearbox & feed tube, unitized on a skid with control panel. Excellent condition. FCA Europe.


Alfa-Laval FPNX 418B-31G decanter centrifuge, 316SS.

Max bowl speed 4000 RPM, 3158 G's, liquid discharged by gravity, 110mm hardsurfaced Esbjerg conveyor, 30 KW ABB motor 380/3/50/1450 RPM, Viscotherm hydraulic back- drive system, guards, feed tube, chutes, piping, valves mounted on SS stand, sanitary feed pump, solids take- away conve


Alfa-Laval NX 418B-31G decanter centrifuge, 316SS.

Max bowl speed 4000 RPM, 3158 G's, liquid discharged by gravity, 110mm hardsurfaced Esbjerg conveyor, 40 HP motor 575/3/60/1775 RPM, pully backdrive, guards, 159:1 gearbox & feed tube, unitized on a stand with control panel. Very good condition. FCA Canada.


Alfa-Laval ALDEC 408 decanter centrifuge, 316SS.

Max bowl speed 3600 RPM, 2515 x G, 353 x 1760mm bowl ID (14 x 69") 10 deg beach angle, 110mm single lead hard- surfaced conveyor, 22 KW motor 380/3/50, 15 KW backdriv 97:1 3.0 knm gearbox, guards, polymer feed tube, vibra- tion isolators/switch, unitized on a stand w/chutes. 2002 vinta
