Westfalia HDA 30-06-006 nozzle centrifuge, 316SS.
Max bowl speed 7480 RPM, 8265 x G, rated @ 6000 LPH, sanitary yeast design, 11 KW motor 460/3/50/1750 RPM, 3 sets of nozzles and top piping. No tools or controls. 1991 vintage. Very good condition.
Westfalia HDB 50-06-006 nozzle centrifuge, 316SS.
Max bowl speed 5920 RPM, rated @ 50 GPM, 22 KW motor 220/380/3/50/60/1460 RPM. Missing centripetal pump assembly. 1988 vintage. Excellent condition.
Westfalia KDA 30-02-177 quark separator, 316SS.
Max bowl speed 5350 RPM, rated @ 10,000 LPH input, 2500 KPH output, 20 KW motor 380/3/50/2910 RPM. No sludge tank, back-pressure valve, base frame, tools or controls. 1980 vintage. Very good condition
Westfalia NA 7-06-076 clarifier centrifuge, 316SS.
Max bowl speed 8510 RPM, rated @ 5000 LPH. Combination desludger/nozzle bowl, liquid discharged under pressure. 7.5 HP motor 230/460/3/60/1800 RPM with piping, valves, gauges, turbidity meter, timing
(2) Westfalia SDA 130-76-107 nozzle centrifuges, 316SS.
Max bowl speed 4500 RPM, rated @ 250 CMPH, liquid phase discharged under pressure, concentrated starch discharged into solids vessel; one with wash water feature, one without, 132 KW motor 380/3/50/30
Westfalia CNB 130-01-076 bacteria separator, 316SS.
Max bowl speed 4500 RPM, rated 15,000 LPH. 22 KW motor 380/3/50/1450 RPM, base plate, water harness, tools and control panel. 1992 vintage. Excellent condition. Located in Europe.
(3) Westfalia HDA 50-06-006 nozzle centrifuges, 316SS.
Max bowl speed 5600 RPM, rated @ 12,000 LPH. 30 KW motor 380/660/3/50/1450 RPM. No tools or controls. 1975 vintage. Very good condition. Located in UK.
Westfalia KDA 30-02-177 quark separator, 316SS.
Max bowl speed 5350 RPM, rated @ 10,000 LPH input, 2500 KPH output, 20 KW motor 380/3/50/2910 RPM, 100 L sludge tank, flow regulation valve, manometer, pneumatic counter pressure valve for whey outlet
Westfalia HFG 12036 nozzle centrifuge, 316SS.
Max bowl speed 6000 RPM, rated @ 330 GPM. 50 HP motor 230/460/3/60/1770 RPM with fluid clutch, tools and manual. Equivalent to: HDB 75-06-016.
Westfalia CNB 215-01-076 bacteria separator, 316SS.
Max bowl speed 4500 RPM, rated 25,000 LPH. Includes bowl, base plate, sludge tank, all inlet/outlet pipes, flow meter, water valve cover, control panel with GEA Operator Panel and manual. Does not inc
Westfalia NA 7-03-076 yogurt separator module, 316SS.
Max bowl speed 8500 RPM, rated @ 5000 LPH. Combination desludger/nozzle bowl, heavy liquid phase discharged under pressure, 4 KW motor 400/3/50/1410 RPM, valves, water harness, gauges, flow meter, sol
Westfalia CND 20-01-076 bacteria separator, 316SS.
Max bowl speed 6255 RPM, rated 5000 LPH. 7.5 KW motor 380/3/50/1445 RPM, all valves, flowmeter, base frame, tools and control panel. 1999 vintage. Excellent condition. Located in Europe.
Westfalia KDA 18-02-177 CIP quark separator, 316SS.
Max bowl speed 5350 RPM, rated @ 1500 kg/hr, 3300 PPH, SS motor and base. 20 KW motor 380/3/50/2905 RPM, 0.75 KW scraper blade motor, scraper, manometer, counter pressure valve, flow meter and control
Westfalia KDB 16-02-076 quark/yogurt nozzle separator, 316SS.
Max bowl speed 6000 RPM, rated @ 4000-5400 LPH input, 900-1100 KPH output @ 18%. 22 KW motor 400/690/3/50/1480 RPM, solids cyclone, flow meter, filters, valves, sensors, base frame, vibration isolator
Westfalia CND 215-01-076 bacteria separator, 316SS.
Max bowl speed 4870 RPM, rated 25,000 LPH. 37 KW motor 380/3/60/1770 RPM, base plate, manometers, flow meter, water valves, all inlet/outlet pipes with pumps, counter pressure valve and tool. 1996 vin
(5) Alfa-Laval BTUX 510T-34CEP discs only.
Part #07-220-000. Small diameter 5", large diameter 13 7/8". Never used. 9 sets available.
Westfalia RN 9004 warm milk clarifier, 316SS.
Max bowl speed 6500 RPM, rated @ 20,000 PPH, 25 HP motor 220/3/60 and tools. Very good condition.
Westfalia MTA 50-03-024 milk separator, SS.
Rated @ 5000 LPH, 1250 GPH, light phase pumped, heavy phase discharged by gravity. 9 HP motor is missing. Excellent condition. Tools included.
Westfalia EG 10006 3-stage Lurgi extractor, 316SS.
Max bowl speed 3700 RPM, 20 HP XP motor 230/460/3/60. Very good condition.
(3) Westfalia TTA 50-02-066 acid tar separators, 316SS.
Max bowl speed 4220 RPM, rated @ 12,000 LPH, light phase discharged under pressure, 11 KW motor 230/460/3/60. Used to refine mineral oil, paraffin and waste oil with sulfuric acid. 1975 vintage. Excel
