Alfa-Laval WSPX 403 SGP-31G lab clarifier, 316SS.

Max bowl speed 9512 RPM, 11,130 x G, rated @ 1000 LPH, max solids capacity 11 LPH, 0-100C temp range. Liquid discharged under pressure, low shear disc inlet design, 2.2 KW motor 415/3/50/1450 RPM, tools & control panel. Mounted on a stand. 2007 vintage. Excellent condition. FCA Austra


Alfa-Laval WSPX 403 SGP-31G lab clarifier, 316SS.

Max bowl speed 9512 RPM, 11,130 x G, rated @ 1000 LPH, max solids capacity 11 LPH, 0-100C temp range. Liquid discharged under pressure, low shear disc inlet design, 2.2 KW motor 415/3/50/1450 RPM and tools. FCA Europe. Reconditioned to "as new" with 6 mo mechanical warranty


UNUSED: Alfa-Laval WSPX 403 SGP-31G lab clarifier, 316SS.

Max bowl speed 9512 RPM, 11,130 x G, rated @ 1000 LPH, max solids capacity 11 LPH, 0-100C temp range. Liquid discharged under pressure, low shear disc inlet design, 2.2 KW motor 415/3/50/1450 RPM & tools. 2007 vintage. FCA Europe.


Alfa-Laval LAPX 404 SGP-31G sanitary lab clarifier, 316SS.

Max bowl speed 9500 RPM, 11,000 x G, rated @ 4000 LPH, max solids capacity 33 LPH, 0-100C temp range. Liquid discharged under pressure, low shear disc inlet design, 3.3 KW motor 380/3/50, tools, vibration isolators and control panel. Reconditioned to "as new" with 6 month mechanical


Alfa-Laval LAPX 404 SGP-31G CLARA 20 clarifier, 316SS.

Max bowl speed 9500 RPM, 11,000 x G, rated @ 4000 LPH, max solids capacity 33 LPH, 0-100C temp range. Liquid discharged under pressure, low shear disc inlet design, 3.3 KW motor 380/3/50, tools & control panel. Unitized on a portable cart. Excellent condition. 2002 vinta


Alfa-Laval LAPX 404 SGP-31G CLARA 20 clarifier, 316SS.

Max bowl speed 9500 RPM, 11,000 x G, rated @ 4000 LPH, max solids capacity 33 LPH, 0-100C temp range. Liquid discharged under pressure, low shear disc inlet design, 3.7 KW motor 460/3/60, piping, tools & control panel. Unitized on a portable cart. Excellent condition.


Alfa-Laval LOPX 705 SFD-30 clarifier, SS.

Liquid phase discharged under pressure, self-triggered ejection of solids via dosing ring, 4 KW motor 380/3/50 /1500 RPM. No tools or controls. Very good condition. Rated @ 1250 LPH on SAE 40 oil @ 90C. 1994 vintage. FOB Bangladesh.


(2) Alfa-Laval LOPX 705 SFD-34 clarifiers, SS.

Liquid phase discharged under pressure, self-triggered ejection of solids via dosing ring, 4 KW motor 380/3/50 /1500 RPM with tools & controls. Very good condition. Rated @ 1250 LPH on SAE 40 oil @ 90C. FCA Bangladesh.


(4) Alfa-Laval LOPX 705 SFD-34 clarifiers, SS.

Liquid phase discharged under pressure, self-triggered ejection of solids via dosing ring, 4 KW motor 380/3/50 /1500 RPM with tools & controls. Excellent condition. Rated @ 1250 LPH on SAE 40 oil @ 90C. FCA Europe. 1999 vintage.


(2) Alfa-Laval LOPX 705 SFD-30 clarifiers, SS.

Liquid phase discharged under pressure, self-triggered ejection of solids via dosing ring, 4 KW motor 460/3/60 /1800 RPM. No tools or controls. Very good condition. Max bowl speed 7540, rated @ 1250 LPH on lube oil. 1995 vintage. FOB Bangladesh.


Alfa-Laval BTPX 205 SGD-34CDP-60 biotech clarifier, 316SS.

Max bowl speed 9650 RPM, 12,800 G's, rated @ 1200 LPH. steam sterilizable, gas-tite, liquid phase discharged under pressure, 7.5 HP XP motor 230/460/3/60/3490 RPM, cyclone, water harness, tools, controls, SIP module, all piping, valves and manuals. Unitized on 3 skids. 1988 vinta


Alfa-Laval BTPX 205 SGD-34CDP-50 clarifier, 316SS.

Max bowl speed 9650 RPM, 12,800 G's, steam sterilizable gastite, liquid phase discharged under pressure, 6.5 KW motor 415/3/50/2900 RPM, cyclone, tools, piping, water harness & controls. Unitized on skid. FCA UK. 1988 vintage. Very good condition.


Alfa-Laval BRPX 207-35S-60 clarifier centrifuge, 316 SS.

Deep sludge cover design, 10 HP motor, complete with timer controls & tools. Prior use: Dairy. 1974 vintage.


(3) De Laval FBRPX 207 SGV-39C-60 clarifiers, 316SS.

10 HP XP motor, sub-base, complete with timers and control panel. Good condition.


Alfa-Laval VNPX 307 SGP-34 clarifier centrifuge, 316SS.

Rated @ 5000 LPH, liquid discharged under pressure, 20 HP motor 230/460/3/60/1750 RPM, feed pump, tools and control panel on portable cart. Excellent condition. **MISSING TOP COVER**


Alfa-Laval MRPX 207 SGV-34 clarifier centrifuge, 316SS.

Rated @ 10,000 LPH, 15 KW motor 380/3/50 with tools and control panel on portable skid. FCA Europe.


Alfa-Laval BRPX 207 SGV-34 clarifier, 316SS.

Max bowl speed 6250 RPM, rated @ 6000 LPH, liquid dis- charge under pressure, 7.5 KW motor 400/3/50/1440 RPM, feed pump, water harness and tools. No controls. Reconditioned to "as new" with full mechanical warranty FCA Europe. New control panel available: add $12,500.


(2) Alfa-Laval LOPX 707 SFD-34-650 clarifier, SS.

Liquid phase discharged under pressure, self-triggered ejection of solids via dosing ring, 14 KW motor 460/3/ 60/1750 RPM. No tools or controls. Very good condition. FCA India.


Alfa-Laval BRPX 207 SGV-39-60 clarifier, 316SS.

Max bowl speed 6250 RPM, deep sludge cover, liquid phas discharged under pressure, 10 HP motor 480/3/60/1750RPM No tools or controls. Prior use: Nutraceuticals. Very good condition.


Alfa-Laval LOPX 707 SFD-34-60 clarifier, SS.

Max bowl speed 5148 RPM, liquid phase discharged under pressure, partial ejection of solids via dosing ring, 14 KW motor 460/3/60/1750 RPM. No tools, no controls. 1994 vintage. Very good condition. FCA India.


Alfa-Laval CLARA 80 VNPX 507 clarification module, 316SS.

Max bowl speed 8400 RPM, rated @ 9000 LPH, liquid discharged under pressure, 11 KW motor 380/3/50/1450 RPM, valves, piping, feed pump, control panel and tools, unitized on a common portable cart. Excellent condition 2011 vintage.


(2) Alfa-Laval LOPX 707 SFD-34 clarifiers, SS.

Max bowl speed 5148 RPM, liquid phase discharged under pressure, partial ejection of solids via dosing ring, 14 KW motor 460/3/60/1750 RPM. No tools, no controls. 1994 vintage. Very good condition. FCA Bangladesh.


Alfa-Laval VNPX 407 SGP-34-50 clarifier centrifuge, 316SS.

Max bowl speed 7310 RPM, rated @ 5000 LPH, liquid discharged under pressure, 11 KW motor 380/3/50/1450 RPM. No tools or controls. Good condition. FCA Europe.


Alfa-Laval VNPX 307 SGP-34 clarifier centrifuge, 316SS.

Rated @ 5000 LPH, liquid discharged under pressure, 20 HP motor 230/460/3/60/1750 RPM, feed pump & control panel on portable cart. No tools. Excellent condition.


Alfa-Laval VNPX 407 SGP-34 clarifier centrifuge, 316SS.

Max bowl speed 7310 RPM, rated @ 5000 LPH, liquid dis- charged under pressure, 11 KW motor 380/3/50/1450 RPM. No tools or controls. Very good condition. FCA Europe.


Alfa-Laval UVPX 207-34A clarifier, 316SS.

Max bowl speed 6250 RPM, liquid phase discharged by gravity, 6.6 KW motor 380/3/60/1450 RPM, tools and gravity discs. Reconditioned to "as new." FCA Europe.


Alfa-Laval BRPX 309 clarifier centrifuge, 316 SS.

15 HP motor 230/460/3/60/1775 RPM. Very good condition.


(2) Alfa-Laval HMBRPX 309-34S-50 clarifiers, 316SS.

Hermetic design, liquid discharged under pressure, 11 KW motor 380/3/50/1420 RPM, control panel, tools, spares & manual. Excellent condition. FCA Europe.


(2) Alfa-Laval LOPX 709 SFD-34-60 lube oil purifiers, SS.

Liquid phase discharged under pressure, self-triggered ejection of solids via dosing ring, 20 HP motor 460/3/ 60/1800 RPM, control panel and tools. 1994 vintage. Very good condition. FCA India.


(3) Alfa-Laval BRPX 309 SGT-34-60 clarifiers, 316SS.

Max bowl speed 5600 RPM, rated @ 25 GPM. Liquid phase discharged under pressure, 15 HP motor 460/3/60/1775RPM 2 shallow covers, 1 deep sludge cover design. No tools, no controls. Good rebuildable condition. Reconditioned price includes water harness, tools, timer/star


Alfa-Laval LOPX 709 SFD-34 lube oil purifier, SS.

Liquid phase discharged under pressure, self-triggered ejection of solids via dosing ring, 15 KW motor 380/3/ 50/1500 RPM, control panel, tools & pumps unitized on a tank. 1998 vintage. Excellent condition. FCA Europe.


(6) Alfa-Laval LOPX 709 SFD-34 lube oil purifiers, SS.

Liquid phase discharged under pressure, self-triggered ejection of solids via dosing ring, 20 HP motor 460/3/ 60/1800 RPM, control panel and tools. 1994 vintage. Very good condition. FCA India.


Alfa-Laval MRPX 409 SGV-34 clarifier, 316SS.

Max bowl speed 5600 RPM, rated @ 20,000 LPH, 45,000 PPH 15 KW motor 380/3/50/1450 RPM, base frame and tools. No control panel. Very good condition. FCA UK.


Alfa-Laval MRPX 409 SGV-34 clarifier, 316SS.

Max bowl speed 5600 RPM, rated @ 20,000 LPH, 45,000 PPH 20 HP motor 230/460/3/60/1750 RPM. No tools or control. Very good condition.


Alfa-Laval MRPX 309 SGV-34 clarifier, 316SS.

Max bowl speed 5600 RPM, rated @ 20,000 LPH, 45,000 PPH 18 KW motor 230/460/3/60/1750 RPM, base frame, tools & NEW PLC control panel. Excellent condition.


Alfa-Laval LOPX 709 SFD-34 lube oil purifier, SS.

Max bowl speed 5175 RPM, liquid phase discharged under pressure, 12 KW motor 380/3/50/1500 RPM with tools and control panel. 2001 vintage. Very good condition. FCA Europe.


Alfa-Laval MRPX 409 SGV-34 clarifier, 316SS.

Max bowl speed 5600 RPM, rated @ 20,000 LPH, 45,000 PPH 20 HP motor 230/460/3/60/1750 RPM, water harness, tools starter/timer controls, unitized on a portable cart. Prior use: Yeast fermentation. Very good condition. Reconditioned price includes 6 mo mechanical warranty.


Alfa-Laval BRPX 309 SFV-34C clarifier, 316SS.

Self-trigger, variable ejection, liquid discharge under pressure, 11 KW motor 380/3/50/1420 RPM, control panel & spare parts. Good condition.


Alfa-Laval BRPX 309 clarifier centrifuge, 316SS.

Max bowl speed 6500 RPM, rated @ 15,000 LPH (3300 GPH). 15 HP motor 230/460/3/60/1750 RPM, water harness, tools and control panel. Excellent running condition.


(3) Alfa-Laval MAPX 210 TGT-39-60 clarifiers, 316SS.

Max bowl speed 5040 RPM, rated @ 50 GPM on diesel oil, liquid phase discharged under pressure, 15 HP motor 230/460/3/60/1760 RPM, feed pump, water harness, tools, timer/control panel & manual. Reconditioned with 6 month mechanical warranty.


Alfa-Laval VNPX 510 SGD-34-50 clarifier centrifuge, 316SS.

Max bowl speed 6210 RPM, liquid discharged under pres- sure, 22 KW motor 415/3/50/1460 RPM. No control panel, no tools. Very good condition. FCA India.


Alfa-Laval VNPX 510 SGD-34-50 clarifier centrifuge, 316SS.

Max bowl speed 6235 RPM, timed solids discharge, liquid discharged under pressure, 22 KW motor 380/3/50/3000RPM NO water harness, base plate, control panel or tools. Very good condition. FCA India.


Alfa-Laval VNPX 310 SGV-34 clarifier centrifuge, 316SS.

Max bowl speed 6210 RPM, liquid discharged under pres- sure, 22 KW motor 380/3/50/1450 RPM with control panel and tools. Skid-mounted. Very good condition. FCA NZ. 1977 vintage.


Alfa-Laval BREW 300 (BRPX 710 SFD-34CGL) clarifier module.

Max bowl speed 7488 RPM, rated at 180 hl/hr (154 bbl/h) liquid discharged under pressure, solids discharge pump w/cyclone tank, 30 KW motor 460/3/60/1800 RPM, unitized on a common skid with all valves, piping, control panel tools, spares and manual. 2001 vintage. Excellent cond.


Alfa-Laval VNPX 410 SGD-34 clarifier centrifuge, 316SS.

Max bowl speed 6210 RPM, liquid discharged under pressure, 22 KW motor 380/3/50/1450 RPM with control panel. No tools. Unitized on a portable skid. Excellent condition. FCA Europe.


Alfa-Laval VNPX 710 SGD-34GL clarifier centrifuge, 316SS.

Max bowl speed 7432RPM, liquid discharged under pressur 22 KW motor 415/3/50, solids discharge pump, controls, sludge tank & tools, unitized on portable skid. Prior use: Winery. Excellent condition. FCA Europe.


Alfa-Laval VNPX 510 SGD-34GS clarifier centrifuge, 316SS.

Max bowl speed 6235 RPM, timed solids discharge, liquid discharged under pressure, 22 KW motor 380/3/50/1450 RPM, top piping and control panel on a skid. FCA Europe. Excellent condition.


Alfa-Laval BRPX 213 SGP-35S clarifier centrifuge, 316SS.

Rated @ 30,000 LPH, 18.5 KW motor 380/3/50/1460 RPM. Some tools, no controls. Reconditioned to "as new."


Alfa-Laval BRPX 513 SFD-31CGL-60 clarifier, 316SS.

Max bowl speed 5195 RPM, liquid phase discharged under pressure via hydrohermetical seal, self-triggered solid ejection, partial discharge feature for dryer solids & minimal liquid loss. 25 HP belt drive 230/460/3/60/1750 solids cyclone, tools and starter/timer control panel. Prior use:


Alfa-Laval BRPX 213-35S clarifier centrifuge, 316SS.

Rated @ 30,000 LPH, 18.5 KW motor 380/3/50/1450 RPM, tools & control panel. Reconditioned. FCA Europe.
