Noxon DC40FC-CC decanter, epoxy-coated CS.

Max bowl speed 2200 RPM, 2162 Gs, co-current design. Bowl ID: 800 x 2446mm = 31.5 x 96.3". Rated @ 25-50 m3/hr (220 GPM max), 1600kg max dry solid STC tiles on feed zone, conveyor and cake discharge ports. 55 KW ABB main drive 440/3/60/1750 RPM, 30 KW backdrive both with VFDs, feed tube, guards, lube system and control panel. Prior use: Circuit board mfg. 2011 vintage. Excellent condition; never used.

The Noxon DC40FC-CC decanter, epoxy-coated CS, is engineered for optimal performance in various industrial applications, particularly in the processing of circuit boards. With a maximum bowl speed of 2200 RPM and a centrifugal force of 2162 Gs, this decanter is designed to efficiently separate solids from liquids, ensuring high throughput and superior separation efficiency. The co-current design of the decanter enhances the flow of materials through the system, allowing for a rated capacity of 25-50 m³/hr (220 GPM max). This makes it an ideal choice for operations requiring reliable and continuous processing of materials, such as those found in the electronics manufacturing sector. The bowl dimensions of 800 x 2446 mm (31.5 x 96.3 inches) provide ample space for effective separation, while the robust construction ensures longevity and durability under demanding conditions.

Equipped with a powerful 55 KW ABB main drive operating at 440/3/60/1750 RPM and a 30 KW backdrive, both featuring variable frequency drives (VFDs), the Noxon DC40FC-CC decanter offers precise control over the processing parameters. This flexibility allows operators to adjust the speed and torque to match the specific requirements of the materials being processed, optimizing performance and energy efficiency. The inclusion of a feed tube, guards, lubrication system, and a control panel further enhances the usability and safety of this equipment. With a maximum dry solid capacity of 1600 kg in the feed zone, conveyor, and cake discharge ports, this decanter is capable of handling substantial loads while maintaining operational integrity. Despite its 2011 vintage, the decanter is in excellent condition and has never been used, making it a valuable addition to any industrial setup looking to enhance its processing capabilities.
