Description:
Max bowl speed 2700 RPM, 2000 Gs, 478 x 2438mm bowl = 19" x 96", rated @ 150 GPM. 10 degree beach, 70mm single lead hardsurfaced conveyor, 60 HP motor 460/3/60/1770 RPM, hydraulic backdrive, guards, feed tube and control panel. Prior use: Stillage dewatering. 1989 vintage. Very good condition.
The Alfa-Laval AVNX 5060B-31G decanter centrifuge, 316SS, is engineered for high-performance separation processes, particularly in the stillage dewatering applications. With a maximum bowl speed of 2700 RPM and the ability to generate up to 2000 Gs, this centrifuge is designed to efficiently separate solids from liquids, ensuring optimal clarity and purity of the output. The bowl dimensions of 478 x 2438mm (19" x 96") provide a substantial surface area for effective separation, while the rated capacity of 150 GPM allows for high throughput, making it an ideal choice for industrial operations that require reliable and continuous processing. The 10-degree beach angle enhances the sedimentation process, ensuring that solids are effectively conveyed towards the discharge outlet, thereby maximizing the efficiency of the separation process.
Constructed from 316 stainless steel, the Alfa-Laval AVNX 5060B-31G is built to withstand the rigors of industrial environments, offering excellent corrosion resistance and durability. The unit is powered by a robust 60 HP motor operating at 460V, 3-phase, 60Hz, and 1770 RPM, ensuring consistent and reliable performance. The hydraulic backdrive system enhances operational efficiency by providing smooth and controlled adjustments to the bowl speed, which is crucial for optimizing the separation process based on varying feed conditions. Additionally, the inclusion of guards, a feed tube, and a control panel ensures that the centrifuge operates safely and effectively, allowing operators to monitor and adjust settings with ease. With prior use in stillage dewatering and its 1989 vintage, this centrifuge has been maintained in very good condition, making it a valuable asset for businesses looking to enhance their separation capabilities.
Key Features:
High-Speed Performance, Durable Construction, Efficient Separation, Hydraulic Backdrive System, User-Friendly Control Panel
